모 델 | 무선통신 |
---|---|
BHT-1461BWB-CE | IEEE802.11b / g / n 블루투스 |
현장에서 최고의 생산성을 제공하도록 설계되었습니다.
Type | BHT-1461BWB-CE | ||
---|---|---|---|
OS | Windows® Embedded Compact 7 | ||
CPU | ARM Cortex-A8 800MHz | ||
Memory | Flash ROM | 2.0GB(1.2GB for user area) | |
Display |
Number of Dots(1) |
3.2 inch WVGA(480×800 dots) | |
Display device | Liquid crystal dot matrix display(color) | ||
Back light | White LED | ||
Scanner | Mode | Advanced scan plus (CCD) | |
Barcode | EAN-13/8(JAN-13/8), UPC-A/E、UPC/EAN(Add-on embedded), Interleaved 2 of 5(ITF), Standard 2 of 5(STF), CODABAR(NW-7), CODE39、CODE93, CODE128, GS1-128(EAN-128), GS1 Databar(RSS) |
||
Minimum resolution | 0.125mm | ||
Reading reference position | 110mm | ||
Scan Confirmation | LED in two colors:Blue/red, speaker, vibrator | ||
Key input section | Number of keys | 21keys(including power key) + cross cursor key + 3trigger Keys | |
Touch panel | Resistive; working load: 1N | ||
Communication |
Wireless LAN |
Suitable standard |
IEEE802.11b/g/nCompliant |
Frequency | 2.4GHz band | ||
Communication distance(2) |
IEEE802.11n:indoors=approx. 50m、IEEE802.11b/g/n:indoors=approx. 75m、outdoors=approx.200m | ||
Transmission speed(2) |
IEEE802.11b:11/5.5/2/1Mbps、IEEE802.11g:54/48/36/24/18/12/9/6Mbps、 IEEE802.11n:65/58.5/52/39/26/19.5/13/6.5Mbps |
||
access method | Infrastructure mode | ||
Security | WEP40,128、WPA-PSK(TKIP,AES)、WPA2-PSK(TKIP,AES)、WPA-1x(TKIP,AES/EAP-TLS, PEAP, LEAP, EAP-FAST)、WPA2-1x(TKIP,AES/EAP-TLS, PEAP, LEAP, EAP-FAST)、802.1x(WEP/EAP-TLS, PEAP, LEAP, EAP-FAST) | ||
Bluetooth® | Bluetooth Ver.2.1 + EDR based class 2 | ||
Card slot | microSDHC or microSD(up to 32GB)×1(FAT32 compliant) | ||
Power | Main battery | Lithium-ion battery | |
Operating time(3) | 36 hours(4)/30 hours(5) | ||
Additional functionality | Clock, speaker, vibrator, battery and voltage in | ||
Environmental performance | Operating temperature |
-20~50℃(6) |
|
Security level | IP65 | ||
Drop resistance(7) |
Dropped from 2.0m/1.5m above concrete floor, on all 6 faces, 10 times each (total 60 times) | ||
Mass(including battery) | Approx. 255g |
Holder : BHT 통신 장치 및 업 레벨 장치와 데이터 통신을 수행합니다.
CU-AR1-14 | CU-AL1-14 | CU-AU1-14 |
---|---|---|
RS-232C 통신 재충전 |
이더넷 통신 재충전 |
USB 통신 재충전 |
각종 BHT 본체 충전 방식 및 백업 카트리지 충전 방식의 라인업
CH-A4-14 | CH-1104 |
---|---|
4개의 직렬 유닛 충전기 | 직렬 배터리 충전기 4개 |
BHT-1400 시리즈용 배터리
BT-140LA-C | BT-110LA |
---|---|
리튬 이온 배터리 + 배터리 덮개 | 리튬 이온 배터리 전용 |
SCBHT-1400 | WHBHT-1400 | NSBHT-1300 |
---|---|---|
소프트 케이스 | 허리 케이스 | 넥 스트랩 |
