모 델 | 무선통신 |
---|---|
BHT-1361B-CE | - |
BHT-1361BWB-CE | IEEE802.11b / g / n 블루투스 |
BHT-1300 시리즈 활용 예시
Type | BHT-1306B | BHT-1306BWB | |||
---|---|---|---|---|---|
OS | BHT-OS | ||||
CPU | 32bit RISC microprocessor | ||||
Memory | Flash ROM(1) | 64MB(45MB for user area) | |||
Display | Number of Dots(2) | QVGA(240×320 dots) | |||
Display device | Liauid crystal dot matrix display (color) | ||||
Displayable characters | 16-dot font | 15(2-bite characters)×20 rows, 30(1-bite characters)×20 rows | |||
24-dot font | 10(2-bite characters)×13 rows, 20(1-bite characters)×13 rows | ||||
Back light | White LED | ||||
Scanner | Mode | Advanced scan plus(CCD) | |||
Decode | EAN-13/-8(JAN-13/-8), UPC-A/-E, UPC/EAN(Add-on embedded), Interleaved 2 of 5、CODABAR(NW-7), CODE39, CODE93, CODE128, GS1-128(EAN-128), Standard 2 of 5(STF), GS1 Databar(RSS) |
||||
Minimum resolution | 0.125mm | ||||
Reading reference position | 50mm | ||||
Scan Confirmation | LED in three colors: Blue/red/green, speaker, vibration | ||||
Key input section | Number of keys | 21 keys (including power key) + Cross-hair cursor key + 3 trigger keys | |||
Communication | Optical I/F |
Communication mode |
Infrared ray (IrDA Ver.1.2[low power]physical signaling layer-comploant) | ||
Transmission spped |
Up to 115.2kbps、460.8kbps | ||||
Communication distance |
Approximately 0.15m MAX. | ||||
Wireless LAN |
Suitable standard |
- | IEEE.802.11b/g/n compliant | ||
Frequency | - | 2.4GHz band | |||
Communication distance(4) |
- | Approx.75m indoors, approx.200m outdoors | |||
Transmission speed(4) |
- | IEEE.802.11b:11/5.5/2/1Mbps、IEEE.802.11g:54/48/36/24/18/12/9/6Mbps、 IEEE802.11n:65/58.5/52/39/26/19.5/13/6.5Mbps |
|||
Access method | - | Infrastructure mode, ad-hoc mode | |||
Security | - | WEP40/128, WPA-PSK(TKIP), WPA2-PSK(AES), WPA-1x(TKIP/EAP-TLS,PEAP), WPA2-1x(AES/EAP-TLS,PEAP), 802.1x(EAP-TLS,PEAP) | |||
Bluetooth | - | Bluetooth Ver.2.1 + EDR based class 2 | |||
Cable I/F | USB Ver.2.0(USB microB) | ||||
Card slot | MicroSD or MicroSDHC(~32GB)×1(FAT32 compliant) | ||||
Additional functionality | Clock, speaker,vibrator, battery, and voltage indicators, keypad backlight, remot wakeup | ||||
Environmental performance | Operating tenperature | -20 to 50℃(5) | |||
Security level | IP54 | ||||
Drop resistance(6) | 2.0m drop on concrete floor /1.2mheight over a concrete floor with each of 6 sides of the enclosure facing down (60 times total) | ||||
Mass | Approx. 188g (With thin battery mouted), approx.206g (with standard battery mounted) |
Type | BHT-1306B | BHT-1306BWB | ||
---|---|---|---|---|
Power | Main battery | Litium ion battery, AAA alkaline batteries x 3(separately sold battery adapter required) | ||
Operating time(7) | Standard battery | 98 hours(8) | 98 hours(8)/42 hours(9) | |
Thin battery | 57 hours(8) | 57 hours(8)/23 hours(9) | ||
AAA alkaline batteries | 55 hours(8) | 55 hours(8)/20 hours(9) |
Holder : BHT 통신 장치 및 업 레벨 장치와 데이터 통신을 수행합니다.
CU-1301A | CU-1311A | CU-1321 | CBBHT-US2000 / C13-4A-CE |
---|---|---|---|
RS-232C 통신 재충전 |
이더넷 통신 재충전 |
USB 통신 재충전 |
USB 통신 재충전 |
각종 BHT 본체 충전 방식 및 백업 카트리지 충전 방식의 라인업
CH-201B | CH-1354 | CH-1104 |
---|---|---|
리튬 이온 배터리 충전기 | 4 개의 직렬 유닛 충전기 | 직렬 배터리 충전기 4개 |
BHT-1300 용 배터리
BT-130LA-CE-C | BT-130L-CE-C | BT-130LA | BT-20LB |
---|---|---|---|
얇은 전지 + 전지 덮개 (1 개) | 표준 배터리 + 배터리 커버 | 얇은 배터리 전용 (1) | 표준 배터리만 |
SCBHT-1300 | WHBHT-1300 | EA-13B | HPBHT-1300B |
---|---|---|---|
소프트 케이스 | 허리 케이스 | 바코드 모델용 터치 스캔 첨부파일 | 헤드 프로텍터 |
